Imagine you're designing a sophisticated navigation system 🗺️ for a modern vehicle that can adapt to different situations:
Strategy and State patterns work exactly like this adaptive navigation system. They provide sophisticated approaches to managing dynamic behavior:
Understanding these behavioral patterns is essential for building applications that need to adapt their behavior dynamically - from game AI and workflow systems to user interfaces and business rule engines.
Behavioral design patterns focus on communication between objects and the assignment of responsibilities. They describe not just patterns of objects or classes but also the patterns of communication between them.
Core Behavioral Pattern Concepts:
Why Behavioral Patterns Matter:
The Strategy Pattern defines a family of algorithms, encapsulates each one, and makes them interchangeable. It lets the algorithm vary independently from clients that use it.
Key Strategy Pattern Concepts:
Strategy Pattern vs Inheritance:
The State Pattern allows an object to alter its behavior when its internal state changes. The object appears to change its class.
State Pattern Foundations:
State Machine Theory:
These patterns mirror how humans naturally organize complex behaviors:
This natural alignment makes these patterns intuitive and powerful for modeling real-world systems.
Without behavioral patterns, complex behavior logic becomes a maintenance nightmare:
// Monolithic approach - everything in one place
class PaymentProcessor {
processPayment(amount, method, cardNumber, expiryDate, cvv, paypalEmail, bankAccount) {
// Complex conditional logic mixed together
if (method === 'credit-card') {
// Credit card validation
if (!this.isValidCardNumber(cardNumber)) {
throw new Error('Invalid card number');
}
if (!this.isValidExpiryDate(expiryDate)) {
throw new Error('Invalid expiry date');
}
if (!this.isValidCVV(cvv)) {
throw new Error('Invalid CVV');
}
// Credit card processing logic
const token = this.tokenizeCard(cardNumber, expiryDate, cvv);
const result = this.chargeCreditCard(token, amount);
if (result.success) {
this.logTransaction('credit-card', amount, result.transactionId);
this.sendReceiptEmail('credit-card', amount);
return { success: true, transactionId: result.transactionId };
} else {
throw new Error(`Credit card payment failed: ${result.error}`);
}
} else if (method === 'paypal') {
// PayPal validation
if (!this.isValidEmail(paypalEmail)) {
throw new Error('Invalid PayPal email');
}
// PayPal processing logic
const paypalResult = this.processPayPal(paypalEmail, amount);
if (paypalResult.success) {
this.logTransaction('paypal', amount, paypalResult.transactionId);
this.sendReceiptEmail('paypal', amount);
return { success: true, transactionId: paypalResult.transactionId };
} else {
throw new Error(`PayPal payment failed: ${paypalResult.error}`);
}
} else if (method === 'bank-transfer') {
// Bank transfer validation
if (!this.isValidBankAccount(bankAccount)) {
throw new Error('Invalid bank account');
}
// Bank transfer processing logic
const bankResult = this.processBankTransfer(bankAccount, amount);
if (bankResult.success) {
this.logTransaction('bank-transfer', amount, bankResult.transactionId);
this.sendReceiptEmail('bank-transfer', amount);
return { success: true, transactionId: bankResult.transactionId };
} else {
throw new Error(`Bank transfer failed: ${bankResult.error}`);
}
} else {
throw new Error(`Unsupported payment method: ${method}`);
}
}
// More methods for validation, processing, etc...
// This class becomes huge and hard to maintain
}
// Problems with this approach:
// 1. Single Responsibility Principle violated - class does too much
// 2. Open/Closed Principle violated - must modify class to add new payment methods
// 3. Hard to test - can't test payment methods in isolation
// 4. Complex conditional logic is hard to follow
// 5. Code duplication (logging, email sending, etc.)
// 6. Method signature becomes unwieldy with many parameters
// 7. Adding new payment methods requires understanding entire class
// Complex state management without State Pattern
class MediaPlayer {
constructor() {
this.state = 'stopped'; // 'stopped', 'playing', 'paused'
this.currentTrack = null;
this.volume = 50;
this.position = 0;
}
play(track = null) {
// Complex state-dependent logic
if (this.state === 'stopped') {
if (track) {
this.currentTrack = track;
this.position = 0;
} else if (!this.currentTrack) {
throw new Error('No track to play');
}
this.state = 'playing';
this.startPlayback();
} else if (this.state === 'paused') {
this.state = 'playing';
this.resumePlayback();
} else if (this.state === 'playing') {
if (track && track !== this.currentTrack) {
this.stopPlayback();
this.currentTrack = track;
this.position = 0;
this.startPlayback();
}
// If same track, do nothing
} else {
throw new Error(`Invalid state: ${this.state}`);
}
}
pause() {
if (this.state === 'playing') {
this.state = 'paused';
this.pausePlayback();
} else if (this.state === 'paused') {
// Already paused, do nothing
} else if (this.state === 'stopped') {
throw new Error('Cannot pause when stopped');
}
}
stop() {
if (this.state === 'playing' || this.state === 'paused') {
this.state = 'stopped';
this.position = 0;
this.stopPlayback();
} else if (this.state === 'stopped') {
// Already stopped, do nothing
}
}
next() {
// Complex logic for each state
if (this.state === 'stopped') {
throw new Error('Cannot go to next track when stopped');
} else if (this.state === 'playing') {
this.stopPlayback();
const nextTrack = this.getNextTrack();
if (nextTrack) {
this.currentTrack = nextTrack;
this.position = 0;
this.startPlayback();
} else {
this.state = 'stopped';
}
} else if (this.state === 'paused') {
const nextTrack = this.getNextTrack();
if (nextTrack) {
this.currentTrack = nextTrack;
this.position = 0;
// Stay in paused state
} else {
this.state = 'stopped';
}
}
}
// Many more methods with complex state-dependent logic...
// Each method needs to handle all possible states
// Adding new states requires modifying every method
}
// Problems:
// 1. Each method contains complex conditional logic for all states
// 2. State transitions are scattered throughout the class
// 3. Adding new states requires modifying every method
// 4. State-dependent behavior is not encapsulated
// 5. Hard to visualize and validate state transitions
// 6. Error-prone - easy to forget to handle all states in all methods
The Strategy Pattern encapsulates algorithms in separate objects and makes them interchangeable at runtime.
// Strategy Pattern implementation
// Strategy interface (implicit in JavaScript)
class PaymentStrategy {
validate(paymentData) {
throw new Error('Subclasses must implement validate method');
}
processPayment(amount, paymentData) {
throw new Error('Subclasses must implement processPayment method');
}
getPaymentType() {
throw new Error('Subclasses must implement getPaymentType method');
}
}
// Concrete Strategy implementations
class CreditCardStrategy extends PaymentStrategy {
validate(paymentData) {
const { cardNumber, expiryDate, cvv, holderName } = paymentData;
const errors = [];
if (!this.isValidCardNumber(cardNumber)) {
errors.push('Invalid card number');
}
if (!this.isValidExpiryDate(expiryDate)) {
errors.push('Invalid expiry date');
}
if (!this.isValidCVV(cvv)) {
errors.push('Invalid CVV');
}
if (!holderName || holderName.trim().length < 2) {
errors.push('Invalid cardholder name');
}
return {
isValid: errors.length === 0,
errors: errors
};
}
async processPayment(amount, paymentData) {
console.log('Processing credit card payment...');
// Tokenize sensitive card data
const token = await this.tokenizeCard(paymentData);
// Process payment with tokenized data
const result = await this.chargeCreditCard(token, amount);
return {
success: result.success,
transactionId: result.transactionId,
method: 'credit-card',
amount: amount,
timestamp: new Date(),
details: {
lastFourDigits: paymentData.cardNumber.slice(-4),
cardType: this.getCardType(paymentData.cardNumber)
}
};
}
getPaymentType() {
return 'credit-card';
}
// Helper methods specific to credit card processing
isValidCardNumber(cardNumber) {
// Luhn algorithm validation
const digits = cardNumber.replace(/\s/g, '');
if (!/^\d{13,19}$/.test(digits)) return false;
let sum = 0;
let isEven = false;
for (let i = digits.length - 1; i >= 0; i--) {
let digit = parseInt(digits[i]);
if (isEven) {
digit *= 2;
if (digit > 9) digit -= 9;
}
sum += digit;
isEven = !isEven;
}
return sum % 10 === 0;
}
isValidExpiryDate(expiryDate) {
const match = expiryDate.match(/^(\d{2})\/(\d{2})$/);
if (!match) return false;
const month = parseInt(match[1]);
const year = parseInt('20' + match[2]);
if (month < 1 || month > 12) return false;
const now = new Date();
const expiry = new Date(year, month - 1);
return expiry > now;
}
isValidCVV(cvv) {
return /^\d{3,4}$/.test(cvv);
}
async tokenizeCard(paymentData) {
// Simulate tokenization process
return `token_${Date.now()}_${Math.random().toString(36).substr(2, 9)}`;
}
async chargeCreditCard(token, amount) {
// Simulate credit card charging
await this.delay(1000);
return {
success: Math.random() > 0.1, // 90% success rate
transactionId: `cc_${Date.now()}`,
error: Math.random() > 0.9 ? 'Insufficient funds' : null
};
}
getCardType(cardNumber) {
const patterns = {
visa: /^4/,
mastercard: /^5[1-5]/,
amex: /^3[47]/,
discover: /^6(?:011|5)/
};
for (const [type, pattern] of Object.entries(patterns)) {
if (pattern.test(cardNumber)) {
return type;
}
}
return 'unknown';
}
delay(ms) {
return new Promise(resolve => setTimeout(resolve, ms));
}
}
class PayPalStrategy extends PaymentStrategy {
validate(paymentData) {
const { email, password } = paymentData;
const errors = [];
if (!this.isValidEmail(email)) {
errors.push('Invalid email address');
}
if (!password || password.length < 6) {
errors.push('Password must be at least 6 characters');
}
return {
isValid: errors.length === 0,
errors: errors
};
}
async processPayment(amount, paymentData) {
console.log('Processing PayPal payment...');
// Authenticate with PayPal
const authResult = await this.authenticatePayPal(paymentData);
if (!authResult.success) {
throw new Error('PayPal authentication failed');
}
// Process payment
const result = await this.processPayPalPayment(authResult.token, amount);
return {
success: result.success,
transactionId: result.transactionId,
method: 'paypal',
amount: amount,
timestamp: new Date(),
details: {
email: paymentData.email,
paypalTransactionId: result.paypalId
}
};
}
getPaymentType() {
return 'paypal';
}
isValidEmail(email) {
return /^[^\s@]+@[^\s@]+\.[^\s@]+$/.test(email);
}
async authenticatePayPal(paymentData) {
// Simulate PayPal authentication
await this.delay(800);
return {
success: Math.random() > 0.05, // 95% success rate
token: `paypal_token_${Date.now()}`,
error: Math.random() > 0.95 ? 'Invalid credentials' : null
};
}
async processPayPalPayment(token, amount) {
// Simulate PayPal payment processing
await this.delay(1200);
return {
success: Math.random() > 0.08, // 92% success rate
transactionId: `pp_${Date.now()}`,
paypalId: `PAY-${Math.random().toString(36).substr(2, 20).toUpperCase()}`,
error: Math.random() > 0.92 ? 'Payment declined by PayPal' : null
};
}
delay(ms) {
return new Promise(resolve => setTimeout(resolve, ms));
}
}
class BankTransferStrategy extends PaymentStrategy {
validate(paymentData) {
const { routingNumber, accountNumber, accountHolderName } = paymentData;
const errors = [];
if (!this.isValidRoutingNumber(routingNumber)) {
errors.push('Invalid routing number');
}
if (!this.isValidAccountNumber(accountNumber)) {
errors.push('Invalid account number');
}
if (!accountHolderName || accountHolderName.trim().length < 2) {
errors.push('Invalid account holder name');
}
return {
isValid: errors.length === 0,
errors: errors
};
}
async processPayment(amount, paymentData) {
console.log('Processing bank transfer payment...');
// Verify bank account
const verificationResult = await this.verifyBankAccount(paymentData);
if (!verificationResult.success) {
throw new Error('Bank account verification failed');
}
// Process bank transfer
const result = await this.processBankTransfer(paymentData, amount);
return {
success: result.success,
transactionId: result.transactionId,
method: 'bank-transfer',
amount: amount,
timestamp: new Date(),
details: {
bankName: verificationResult.bankName,
accountLastFour: paymentData.accountNumber.slice(-4),
processingTime: '3-5 business days'
}
};
}
getPaymentType() {
return 'bank-transfer';
}
isValidRoutingNumber(routingNumber) {
return /^\d{9}$/.test(routingNumber);
}
isValidAccountNumber(accountNumber) {
return /^\d{8,17}$/.test(accountNumber);
}
async verifyBankAccount(paymentData) {
// Simulate bank account verification
await this.delay(2000);
return {
success: Math.random() > 0.15, // 85% success rate
bankName: 'Example Bank',
error: Math.random() > 0.85 ? 'Account not found' : null
};
}
async processBankTransfer(paymentData, amount) {
// Simulate bank transfer processing
await this.delay(1500);
return {
success: Math.random() > 0.12, // 88% success rate
transactionId: `bt_${Date.now()}`,
error: Math.random() > 0.88 ? 'Insufficient funds' : null
};
}
delay(ms) {
return new Promise(resolve => setTimeout(resolve, ms));
}
}
// Context class that uses strategies
class PaymentProcessor {
constructor() {
this.strategy = null;
this.strategies = new Map();
// Register available strategies
this.registerStrategy('credit-card', new CreditCardStrategy());
this.registerStrategy('paypal', new PayPalStrategy());
this.registerStrategy('bank-transfer', new BankTransferStrategy());
}
registerStrategy(name, strategy) {
this.strategies.set(name, strategy);
}
setStrategy(strategyName) {
const strategy = this.strategies.get(strategyName);
if (!strategy) {
throw new Error(`Unknown payment strategy: ${strategyName}`);
}
this.strategy = strategy;
}
getAvailableStrategies() {
return Array.from(this.strategies.keys());
}
validatePaymentData(paymentData) {
if (!this.strategy) {
throw new Error('No payment strategy selected');
}
return this.strategy.validate(paymentData);
}
async processPayment(amount, paymentData) {
if (!this.strategy) {
throw new Error('No payment strategy selected');
}
// Validate payment data first
const validation = this.validatePaymentData(paymentData);
if (!validation.isValid) {
throw new Error(`Validation failed: ${validation.errors.join(', ')}`);
}
try {
// Process payment using selected strategy
const result = await this.strategy.processPayment(amount, paymentData);
// Log transaction
this.logTransaction(result);
// Send confirmation
await this.sendConfirmation(result);
return result;
} catch (error) {
console.error('Payment processing failed:', error.message);
throw error;
}
}
logTransaction(result) {
console.log(`Transaction logged: ${result.transactionId} - ${result.method} - $${result.amount}`);
}
async sendConfirmation(result) {
// Simulate sending confirmation email
console.log(`Confirmation sent for transaction: ${result.transactionId}`);
}
}
// Usage demonstration
console.log('=== Strategy Pattern Demo ===');
const processor = new PaymentProcessor();
// Credit card payment
console.log('\n--- Credit Card Payment ---');
processor.setStrategy('credit-card');
const creditCardData = {
cardNumber: '4532015112830366',
expiryDate: '12/25',
cvv: '123',
holderName: 'John Doe'
};
try {
const result = await processor.processPayment(100.00, creditCardData);
console.log('Payment successful:', result);
} catch (error) {
console.error('Payment failed:', error.message);
}
// PayPal payment
console.log('\n--- PayPal Payment ---');
processor.setStrategy('paypal');
const paypalData = {
email: 'user@example.com',
password: 'securepassword123'
};
try {
const result = await processor.processPayment(75.50, paypalData);
console.log('Payment successful:', result);
} catch (error) {
console.error('Payment failed:', error.message);
}
// Bank transfer payment
console.log('\n--- Bank Transfer Payment ---');
processor.setStrategy('bank-transfer');
const bankData = {
routingNumber: '021000021',
accountNumber: '1234567890',
accountHolderName: 'Jane Smith'
};
try {
const result = await processor.processPayment(250.00, bankData);
console.log('Payment successful:', result);
} catch (error) {
console.error('Payment failed:', error.message);
}
console.log('\nAvailable payment strategies:', processor.getAvailableStrategies());
// Advanced Strategy Pattern with runtime configuration
class SortingStrategy {
sort(array, options = {}) {
throw new Error('Subclasses must implement sort method');
}
getName() {
throw new Error('Subclasses must implement getName method');
}
getComplexity() {
throw new Error('Subclasses must implement getComplexity method');
}
getBestCase() {
return 'N/A';
}
getWorstCase() {
return 'N/A';
}
}
class BubbleSortStrategy extends SortingStrategy {
sort(array, options = {}) {
const { ascending = true, compareFn } = options;
const arr = [...array]; // Don't mutate original
const compare = compareFn || ((a, b) => ascending ? a - b : b - a);
console.log(`Sorting with Bubble Sort (${arr.length} elements)`);
for (let i = 0; i < arr.length - 1; i++) {
for (let j = 0; j < arr.length - i - 1; j++) {
if (compare(arr[j], arr[j + 1]) > 0) {
[arr[j], arr[j + 1]] = [arr[j + 1], arr[j]];
}
}
}
return arr;
}
getName() {
return 'Bubble Sort';
}
getComplexity() {
return {
best: 'O(n)',
average: 'O(n²)',
worst: 'O(n²)',
space: 'O(1)'
};
}
}
class QuickSortStrategy extends SortingStrategy {
sort(array, options = {}) {
const { ascending = true, compareFn } = options;
const compare = compareFn || ((a, b) => ascending ? a - b : b - a);
console.log(`Sorting with Quick Sort (${array.length} elements)`);
return this.quickSort([...array], compare);
}
quickSort(arr, compare) {
if (arr.length <= 1) return arr;
const pivot = arr[Math.floor(arr.length / 2)];
const left = arr.filter((x, index) => index !== Math.floor(arr.length / 2) && compare(x, pivot) <= 0);
const right = arr.filter((x, index) => index !== Math.floor(arr.length / 2) && compare(x, pivot) > 0);
return [
...this.quickSort(left, compare),
pivot,
...this.quickSort(right, compare)
];
}
getName() {
return 'Quick Sort';
}
getComplexity() {
return {
best: 'O(n log n)',
average: 'O(n log n)',
worst: 'O(n²)',
space: 'O(log n)'
};
}
}
class MergeSortStrategy extends SortingStrategy {
sort(array, options = {}) {
const { ascending = true, compareFn } = options;
const compare = compareFn || ((a, b) => ascending ? a - b : b - a);
console.log(`Sorting with Merge Sort (${array.length} elements)`);
return this.mergeSort([...array], compare);
}
mergeSort(arr, compare) {
if (arr.length <= 1) return arr;
const mid = Math.floor(arr.length / 2);
const left = this.mergeSort(arr.slice(0, mid), compare);
const right = this.mergeSort(arr.slice(mid), compare);
return this.merge(left, right, compare);
}
merge(left, right, compare) {
let result = [];
let leftIndex = 0;
let rightIndex = 0;
while (leftIndex < left.length && rightIndex < right.length) {
if (compare(left[leftIndex], right[rightIndex]) <= 0) {
result.push(left[leftIndex]);
leftIndex++;
} else {
result.push(right[rightIndex]);
rightIndex++;
}
}
return result
.concat(left.slice(leftIndex))
.concat(right.slice(rightIndex));
}
getName() {
return 'Merge Sort';
}
getComplexity() {
return {
best: 'O(n log n)',
average: 'O(n log n)',
worst: 'O(n log n)',
space: 'O(n)'
};
}
}
// Smart sorting context with strategy selection
class SmartSorter {
constructor() {
this.strategies = new Map();
this.defaultStrategy = null;
// Register sorting strategies
this.registerStrategy('bubble', new BubbleSortStrategy());
this.registerStrategy('quick', new QuickSortStrategy());
this.registerStrategy('merge', new MergeSortStrategy());
this.setDefaultStrategy('quick');
}
registerStrategy(name, strategy) {
this.strategies.set(name, strategy);
}
setDefaultStrategy(name) {
if (!this.strategies.has(name)) {
throw new Error(`Strategy ${name} not found`);
}
this.defaultStrategy = name;
}
// Automatic strategy selection based on array characteristics
selectOptimalStrategy(array) {
const length = array.length;
if (length <= 10) {
return 'bubble'; // Bubble sort is fine for very small arrays
} else if (length <= 1000) {
return 'quick'; // Quick sort for medium arrays
} else {
return 'merge'; // Merge sort for large arrays (guaranteed O(n log n))
}
}
sort(array, options = {}) {
const {
strategy = null,
autoSelect = false,
ascending = true,
compareFn = null,
showComplexity = false
} = options;
let selectedStrategy;
if (strategy) {
selectedStrategy = strategy;
} else if (autoSelect) {
selectedStrategy = this.selectOptimalStrategy(array);
console.log(`Auto-selected strategy: ${selectedStrategy} for array of length ${array.length}`);
} else {
selectedStrategy = this.defaultStrategy;
}
const sortStrategy = this.strategies.get(selectedStrategy);
if (!sortStrategy) {
throw new Error(`Unknown sorting strategy: ${selectedStrategy}`);
}
if (showComplexity) {
console.log(`${sortStrategy.getName()} Complexity:`, sortStrategy.getComplexity());
}
const startTime = performance.now();
const result = sortStrategy.sort(array, { ascending, compareFn });
const endTime = performance.now();
console.log(`Sorting completed in ${(endTime - startTime).toFixed(2)}ms`);
return result;
}
getAvailableStrategies() {
return Array.from(this.strategies.keys()).map(key => ({
name: key,
displayName: this.strategies.get(key).getName(),
complexity: this.strategies.get(key).getComplexity()
}));
}
benchmark(array, iterations = 1) {
const results = {};
for (const [name, strategy] of this.strategies) {
const times = [];
for (let i = 0; i < iterations; i++) {
const startTime = performance.now();
strategy.sort(array);
const endTime = performance.now();
times.push(endTime - startTime);
}
results[name] = {
strategy: strategy.getName(),
averageTime: times.reduce((sum, time) => sum + time, 0) / times.length,
minTime: Math.min(...times),
maxTime: Math.max(...times),
complexity: strategy.getComplexity()
};
}
return results;
}
}
// Usage demonstration
console.log('\n=== Advanced Strategy Pattern Demo ===');
const sorter = new SmartSorter();
// Test data
const smallArray = [64, 34, 25, 12, 22, 11, 90];
const mediumArray = Array.from({ length: 100 }, () => Math.floor(Math.random() * 1000));
const largeArray = Array.from({ length: 1000 }, () => Math.floor(Math.random() * 10000));
console.log('\nAvailable strategies:');
console.table(sorter.getAvailableStrategies());
// Manual strategy selection
console.log('\n--- Manual Strategy Selection ---');
const quickSorted = sorter.sort(smallArray, { strategy: 'quick', showComplexity: true });
console.log('Original:', smallArray);
console.log('Quick sorted:', quickSorted);
// Automatic strategy selection
console.log('\n--- Automatic Strategy Selection ---');
const autoSortedMedium = sorter.sort(mediumArray, { autoSelect: true });
console.log('Medium array sorted with auto-selected strategy');
const autoSortedLarge = sorter.sort(largeArray, { autoSelect: true });
console.log('Large array sorted with auto-selected strategy');
// Custom comparison function
console.log('\n--- Custom Comparison ---');
const people = [
{ name: 'Alice', age: 30 },
{ name: 'Bob', age: 25 },
{ name: 'Charlie', age: 35 }
];
const sortedByAge = sorter.sort(people, {
strategy: 'merge',
compareFn: (a, b) => a.age - b.age
});
console.log('Sorted by age:', sortedByAge);
// Benchmarking
console.log('\n--- Performance Benchmark ---');
const benchmarkArray = Array.from({ length: 100 }, () => Math.floor(Math.random() * 1000));
const benchmarkResults = sorter.benchmark(benchmarkArray, 5);
console.log('Benchmark results (5 iterations):');
console.table(benchmarkResults);
The State Pattern allows an object to change its behavior when its internal state changes, appearing as if the object changed its class.
// State Pattern implementation for Media Player
// Abstract State class
class MediaPlayerState {
constructor(player) {
this.player = player;
}
play(track = null) {
this.invalidOperation('play');
}
pause() {
this.invalidOperation('pause');
}
stop() {
this.invalidOperation('stop');
}
next() {
this.invalidOperation('next');
}
previous() {
this.invalidOperation('previous');
}
seek(position) {
this.invalidOperation('seek');
}
setVolume(volume) {
// Volume can be changed in any state
this.player.volume = Math.max(0, Math.min(100, volume));
this.player.notifyObservers('volumeChanged', this.player.volume);
}
getStateName() {
throw new Error('Subclasses must implement getStateName method');
}
onEnter() {
// Called when entering this state
console.log(`Entering ${this.getStateName()} state`);
}
onExit() {
// Called when leaving this state
console.log(`Exiting ${this.getStateName()} state`);
}
invalidOperation(operation) {
console.warn(`Cannot ${operation} in ${this.getStateName()} state`);
throw new Error(`Invalid operation: ${operation} not allowed in ${this.getStateName()} state`);
}
}
// Concrete State implementations
class StoppedState extends MediaPlayerState {
play(track = null) {
if (track) {
this.player.currentTrack = track;
} else if (!this.player.currentTrack) {
throw new Error('No track to play');
}
this.player.position = 0;
this.player.startPlayback();
this.player.setState(new PlayingState(this.player));
}
next() {
const nextTrack = this.player.getNextTrack();
if (nextTrack) {
this.player.currentTrack = nextTrack;
this.player.notifyObservers('trackChanged', nextTrack);
}
}
previous() {
const previousTrack = this.player.getPreviousTrack();
if (previousTrack) {
this.player.currentTrack = previousTrack;
this.player.notifyObservers('trackChanged', previousTrack);
}
}
getStateName() {
return 'Stopped';
}
}
class PlayingState extends MediaPlayerState {
play(track = null) {
if (track && track !== this.player.currentTrack) {
// Switch to new track
this.player.stopPlayback();
this.player.currentTrack = track;
this.player.position = 0;
this.player.startPlayback();
this.player.notifyObservers('trackChanged', track);
}
// If same track or no track specified, continue playing
}
pause() {
this.player.pausePlayback();
this.player.setState(new PausedState(this.player));
}
stop() {
this.player.stopPlayback();
this.player.position = 0;
this.player.setState(new StoppedState(this.player));
}
next() {
const nextTrack = this.player.getNextTrack();
if (nextTrack) {
this.player.stopPlayback();
this.player.currentTrack = nextTrack;
this.player.position = 0;
this.player.startPlayback();
this.player.notifyObservers('trackChanged', nextTrack);
} else {
this.stop(); // No more tracks
}
}
previous() {
if (this.player.position > 3) {
// If more than 3 seconds into track, restart current track
this.player.position = 0;
this.player.seek(0);
} else {
// Go to previous track
const previousTrack = this.player.getPreviousTrack();
if (previousTrack) {
this.player.stopPlayback();
this.player.currentTrack = previousTrack;
this.player.position = 0;
this.player.startPlayback();
this.player.notifyObservers('trackChanged', previousTrack);
}
}
}
seek(position) {
if (position >= 0 && position <= this.player.currentTrack.duration) {
this.player.position = position;
this.player.seek(position);
}
}
getStateName() {
return 'Playing';
}
onEnter() {
super.onEnter();
this.player.notifyObservers('playbackStarted', this.player.currentTrack);
}
}
class PausedState extends MediaPlayerState {
play(track = null) {
if (track && track !== this.player.currentTrack) {
// Switch to new track
this.player.currentTrack = track;
this.player.position = 0;
this.player.startPlayback();
this.player.notifyObservers('trackChanged', track);
} else {
// Resume current track
this.player.resumePlayback();
}
this.player.setState(new PlayingState(this.player));
}
stop() {
this.player.position = 0;
this.player.setState(new StoppedState(this.player));
}
next() {
const nextTrack = this.player.getNextTrack();
if (nextTrack) {
this.player.currentTrack = nextTrack;
this.player.position = 0;
this.player.notifyObservers('trackChanged', nextTrack);
// Stay in paused state
} else {
this.stop(); // No more tracks
}
}
previous() {
const previousTrack = this.player.getPreviousTrack();
if (previousTrack) {
this.player.currentTrack = previousTrack;
this.player.position = 0;
this.player.notifyObservers('trackChanged', previousTrack);
// Stay in paused state
}
}
seek(position) {
if (position >= 0 && position <= this.player.currentTrack.duration) {
this.player.position = position;
}
}
getStateName() {
return 'Paused';
}
onEnter() {
super.onEnter();
this.player.notifyObservers('playbackPaused', this.player.currentTrack);
}
}
// Context class - MediaPlayer
class MediaPlayer {
constructor() {
this.state = new StoppedState(this);
this.currentTrack = null;
this.position = 0;
this.volume = 50;
this.playlist = [];
this.currentTrackIndex = 0;
this.observers = [];
}
// State management
setState(newState) {
if (this.state) {
this.state.onExit();
}
this.state = newState;
this.state.onEnter();
this.notifyObservers('stateChanged', this.state.getStateName());
}
getState() {
return this.state.getStateName();
}
// Public interface - delegates to current state
play(track = null) {
this.state.play(track);
}
pause() {
this.state.pause();
}
stop() {
this.state.stop();
}
next() {
this.state.next();
}
previous() {
this.state.previous();
}
seek(position) {
this.state.seek(position);
}
setVolume(volume) {
this.state.setVolume(volume);
}
// Playlist management
setPlaylist(tracks) {
this.playlist = tracks;
this.currentTrackIndex = 0;
if (tracks.length > 0) {
this.currentTrack = tracks[0];
}
this.notifyObservers('playlistChanged', tracks);
}
addToPlaylist(track) {
this.playlist.push(track);
if (this.playlist.length === 1) {
this.currentTrack = track;
this.currentTrackIndex = 0;
}
this.notifyObservers('playlistChanged', this.playlist);
}
getNextTrack() {
if (this.currentTrackIndex < this.playlist.length - 1) {
this.currentTrackIndex++;
return this.playlist[this.currentTrackIndex];
}
return null;
}
getPreviousTrack() {
if (this.currentTrackIndex > 0) {
this.currentTrackIndex--;
return this.playlist[this.currentTrackIndex];
}
return null;
}
// Playback simulation methods
startPlayback() {
console.log(`Starting playback: ${this.currentTrack.title}`);
this.simulatePlayback();
}
pausePlayback() {
console.log(`Pausing playback: ${this.currentTrack.title}`);
if (this.playbackTimer) {
clearInterval(this.playbackTimer);
}
}
resumePlayback() {
console.log(`Resuming playback: ${this.currentTrack.title}`);
this.simulatePlayback();
}
stopPlayback() {
console.log(`Stopping playback: ${this.currentTrack.title}`);
if (this.playbackTimer) {
clearInterval(this.playbackTimer);
}
}
seek(position) {
console.log(`Seeking to ${position}s in ${this.currentTrack.title}`);
}
simulatePlayback() {
// Simulate playback progress
this.playbackTimer = setInterval(() => {
this.position++;
this.notifyObservers('positionChanged', this.position);
// Auto-advance to next track when current track ends
if (this.position >= this.currentTrack.duration) {
if (this.getNextTrack()) {
this.next();
} else {
this.stop();
}
}
}, 1000);
}
// Observer pattern for state change notifications
addObserver(observer) {
this.observers.push(observer);
}
removeObserver(observer) {
const index = this.observers.indexOf(observer);
if (index > -1) {
this.observers.splice(index, 1);
}
}
notifyObservers(event, data) {
this.observers.forEach(observer => {
if (typeof observer === 'function') {
observer(event, data);
} else if (observer.update) {
observer.update(event, data);
}
});
}
// Status methods
getCurrentStatus() {
return {
state: this.state.getStateName(),
currentTrack: this.currentTrack,
position: this.position,
volume: this.volume,
playlist: this.playlist,
currentTrackIndex: this.currentTrackIndex
};
}
}
// Usage demonstration
console.log('\n=== State Pattern Demo ===');
const player = new MediaPlayer();
// Add observer to monitor state changes
player.addObserver((event, data) => {
console.log(`Event: ${event}, Data:`, data);
});
// Create sample playlist
const playlist = [
{ title: 'Song 1', artist: 'Artist A', duration: 180 },
{ title: 'Song 2', artist: 'Artist B', duration: 210 },
{ title: 'Song 3', artist: 'Artist C', duration: 195 }
];
player.setPlaylist(playlist);
console.log('\nInitial state:', player.getState());
console.log('Status:', player.getCurrentStatus());
// Test state transitions
console.log('\n--- Testing State Transitions ---');
try {
// Can't pause when stopped
player.pause();
} catch (error) {
console.log('Expected error:', error.message);
}
// Start playing
player.play();
console.log('After play - State:', player.getState());
// Pause
setTimeout(() => {
player.pause();
console.log('After pause - State:', player.getState());
// Resume
setTimeout(() => {
player.play();
console.log('After resume - State:', player.getState());
// Stop
setTimeout(() => {
player.stop();
console.log('After stop - State:', player.getState());
// Clean up
if (player.playbackTimer) {
clearInterval(player.playbackTimer);
}
}, 1000);
}, 1000);
}, 2000);
Strategy and State patterns revolutionized how I handle complex behavior in applications. Before understanding these patterns, my code was full of giant switch statements and complex if-else chains that were hard to maintain and extend.
The key insight: Instead of asking "what should I do in this situation?", these patterns let you ask "who knows what to do in this situation?" This shift from procedural thinking to object-oriented responsibility delegation makes code much more maintainable.
Strategy pattern taught me that algorithms are first-class citizens that deserve their own classes. State pattern showed me how to model complex state machines elegantly, making state transitions explicit and manageable.
Now that you've mastered behavioral patterns for dynamic behavior, we'll explore Singleton Pattern & Proxy Pattern - structural and creational patterns that control object access and provide sophisticated object interaction mechanisms.
Remember: These patterns aren't about complexity - they're about organizing complexity in maintainable, extensible ways! 🚀✨

I'm Rahul, Sr. Software Engineer (SDE II) and passionate content creator. Sharing my expertise in software development to assist learners.
More about me
